规格型号 |
RU-18-3060 |
RU-18-6030 |
RU-18-10018 |
RU-18-3006 |
RU-18-6003 |
RU-18-10001 | |
交流输入 |
220V±10% | ||||||
额定值范围 |
输出电压 |
0-30V |
0-60V |
0-100V |
0-300V |
0-600V |
0-1000V |
输出电流 |
0-60A |
0-30A |
0-18A |
0-6A |
0-3A |
0-1A | |
输出功率 |
0-1800W |
0-1800W |
0-1800W |
0-1800W |
0-1800W |
0-1000W | |
负载调整率 |
电压 |
≤0.2%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS |
电流 |
≤0.2%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS |
≤0.1%FS | |
设定值解析度 |
电压 |
0.01V |
0.01V |
0.1V |
0.1V |
0.1V |
1V |
电流 |
0.01A |
0.01A |
0.01A |
0.001A |
0.001A |
0.001A | |
回读值解析度 |
电压 |
0.01V |
0.01V |
0.1V |
0.1V |
0.1V |
1V |
电流 |
0.01A |
0.01A |
0.01A |
0.001A |
0.001A |
0.001A | |
设定值精确度 |
电压 |
≤0.1%FS+20mV |
≤0.1%FS+20mV | ≤0.1%FS+100mV |
|||
电流 |
≤0.3%FS+30mA |
≤0.3%FS+10mA | ≤0.3%FS+10mA |
||||
回读值精确度 |
电压 |
≤0.1%FS+20mV |
≤0.1%FS+20mv | ≤0.1%FS+100mV |
|||
电流 |
≤0.3%FS+30mA |
≤0.3%FS+10mA | ≤0.3%FS+10mA |
||||
纹波(20HZ-20MHZ) |
Vpp≤1%FS+100mV |
Vpp≤1%FS+100mV Vrms≤0.3%FS+100mV |
Vpp≤1%FS+300mV |
||||
动态响应时间(10%-90%负载) |
≤5mS | ||||||
电压设定和预置 |
旋转编码器 | ||||||
电流设定和预置 |
旋转编码器 | ||||||
接口 |
标配RS232、RS485 | ||||||
保护功能 |
具有过压保护,过流保护,短路保护,温度保护 | ||||||
散热方式 |
强制风冷 | ||||||
操作环境 |
室内使用设计,温度: 0℃~40℃;湿度:10%~85% RH | ||||||
储存环境 |
温度:-20℃~70℃;湿度:10%~90% RH | ||||||
尺寸(W*H*D) |
218*44*435mm | ||||||
重量 |
4KG左右 |
