系列产品 |
万瑞达型号 |
电压 |
电流 |
功率 |
150V |
VL012-150120 |
0-150V |
0-120A |
1200W |
VL018-150180 |
0-150V |
0-180A |
1800W |
|
VL024-150240 |
0-150V |
0-240A |
2400W |
|
VL03-150300 |
0-150V |
0-300A |
3000W |
|
VL06-150600 |
0-150V |
0-600A |
6000W |
|
VL09-150900 |
0-150V |
0-900A |
9000W |
|
VL12-1501200 |
0-150V |
0-1200A |
12KW |
|
VL15-1501500 |
0-150V |
0-1500A |
15KW |
|
VL18-1501200 |
0-150V |
0-1200A |
18KW |
|
VL24-1501200 |
0-150V |
0-1200A |
24KW |
|
VL30-1501200 |
0-150V |
0-1200A |
30KW |
|
VL40-1501200 |
0-150V |
0-1200A |
40KW |
型号 |
VL012-150120 |
VL018-150180 |
VL024-150240 |
VL03-150300 |
VL06-150600 |
VL09-150900 |
||||||
功率 |
120W |
1200W |
180W |
1800W |
240W |
2400W |
300W |
3000W |
600W |
6000W |
900W |
9000W |
电压范围 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
电流范围 |
0-12A |
0-120A |
0-18A |
0-180A |
0-24A |
0-240A |
0-30A |
0-300A |
0-60A |
0-600A |
0-90A |
0-900A |
定电流模式（CC） |
||||||||||||
量程 |
0-12A |
0-120A |
0-18A |
0-180A |
0-24A |
0-240A |
0-30A |
0-300A |
0-60A |
0-600A |
0-90A |
0-900A |
精度 |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
分辨率 |
1mA |
10mA |
1.5mA |
15mA |
2mA |
20mA |
2.5mA |
25mA |
5mA |
50mA |
7.5mA |
75mA |
定电阻模式（CR ） |
||||||||||||
量程 |
0.025Ω～250Ω |
0.1Ω～5KΩ |
0.0175Ω～175Ω |
0.07Ω～3.5KΩ |
0.0125Ω～125Ω |
0.05Ω～2.5KΩ |
0.01Ω～100Ω |
0.04Ω～2KΩ |
0.005Ω～50Ω |
0.02Ω～1KΩ |
0.004Ω～35Ω |
0.015Ω～700Ω |
精度 |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
||||||
分辨率 |
14 bits |
14 bits |
14 bits |
14 bits |
14 bits |
14 bits |
||||||
定电圧模式（CV） |
||||||||||||
量程 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
精度 |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
||||||
分辨率 |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
定功率模式（CP） |
||||||||||||
量程 |
0-120W |
0-1200W |
0-180W |
0-1800W |
0-240W |
0-2400W |
0-300W |
0-3000W |
0-600W |
0-6000W |
0-900W |
0-9000W |
精度 |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
||||||
分辨率 |
0.6W |
0.6W |
0.6W |
0.6W |
0.6W |
0.6W |
||||||
动态模式 |
||||||||||||
T1&T2 |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
斜率 |
2mA-0.4A/uS |
20mA-4A/uS |
2.5mA-0.5A/uS |
25mA-5A/uS |
4mA-0.8A/uS |
40mA-8A/uS |
5mA-1A/uS |
50mA-10A/uS |
10mA-2A/uS |
0.1A-20A/uS |
14mA-2.8A/uS |
0.14A-28A/uS |
精度 |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
||||||
测量参数 |
||||||||||||
电压范围 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
精度 |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
||||||
分辨率 |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
电流范围 |
0-12A |
0-120A |
0-18A |
0-180A |
0-24A |
0-240A |
0-30A |
0-300A |
0-60A |
0-600A |
0-90A |
0-900A |
精度 |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
||||||
分辨率 |
0.3mA |
3mA |
0.4mA |
4mA |
0.6mA |
6mA |
0.6mA |
6mA |
1.2mA |
12mA |
1.8mA |
18mA |
功率范围 |
0-120W |
0-1200W |
0-180W |
0-1800W |
0-240W |
0-2400W |
0-300W |
0-3000W |
0-600W |
0-6000W |
0-900W |
0-9000W |
精度 |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
||||||
分辨率 |
0.1W |
0.1W |
0.1W |
0.1W |
0.1W |
0.1W |
||||||
常规参数 |
||||||||||||
短路电流 |
120A |
180A |
240A |
300A |
600A |
900A |
||||||
尺寸 (W*H*D) mm |
425 X 175 X 640 |
425 X 175 X 640 |
425 X 175 X 640 |
425 X 175 X 640 |
425 X 350 X 640 |
550 X 635 X 720 |
||||||
重量 (Kg) |
20 |
24 |
28 |
32 |
64 |
116 |
||||||
型号 |
VL12-1501200 |
VL15-1501500 |
VL18-1501200 |
VL24-1501200 |
VL30-1501200 |
VL40-1501200 |
||||||
功率 |
1200W |
12000W |
1500W |
15000W |
1800W |
18000W |
2400W |
24000W |
3000W |
30000W |
4000W |
40000W |
电压范围 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
电流范围 |
0-120A |
0-1200A |
0-150A |
0-1500A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
定电流模式（CC） |
||||||||||||
量程 |
0-120A |
0-1200A |
0-150A |
0-1500A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
精度 |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
0.05%+0.1%FS |
0.1%+0.1%FS |
分辨率 |
10mA |
100mA |
12mA |
120mA |
10mA |
100mA |
10mA |
100mA |
10mA |
100mA |
10mA |
100mA |
定电阻模式（CR ） |
||||||||||||
量程 |
0.0025Ω～25Ω |
0.01Ω～500Ω |
0.002Ω～20Ω |
0.008Ω～400Ω |
0.0025Ω～25Ω |
0.01Ω～500Ω |
0.0025Ω～25Ω |
0.01Ω～500Ω |
0.0025Ω～25Ω |
0.01Ω～500Ω |
0.0025Ω～25Ω |
0.01Ω～500Ω |
精度 |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
Vin/Rset*(0.2%)+0.2%IF.S |
||||||
分辨率 |
14 bits |
14 bits |
14 bits |
14 bits |
14 bits |
14 bits |
||||||
定电圧模式（CV） |
||||||||||||
量程 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
精度 |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
0.05%+0.05%FS |
||||||
分辨率 |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
2mV |
20mV |
定功率模式（CP） |
||||||||||||
量程 |
0-1200W |
0-12000W |
0-1500W |
0-15000W |
0-1800W |
0-18000W |
0-2400W |
0-24000W |
0-3000W |
0-30000W |
0-4000W |
0-40000W |
精度 |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
||||||
分辨率 |
0.6W |
0.6W |
0.6W |
0.6W |
0.6W |
0.6W |
||||||
动态模式 |
||||||||||||
T1&T2 |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
0.025-10mS |
1mS-30S |
斜率 |
20mA-4A/uS |
0.2A-40A/uS |
25mA-5A/uS |
0.25A-50A/uS |
20mA-4A/uS |
0.2A-40A/uS |
20mA-4A/uS |
0.2A-40A/uS |
20mA-4A/uS |
0.2A-40A/uS |
20mA-4A/uS |
0.2A-40A/uS |
精度 |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
10%±20uS |
||||||
测量参数 |
||||||||||||
电压范围 |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
0-15V |
0-150V |
精度 |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
0.025%+0.05%FS |
||||||
分辨率 |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
0.5mV |
5mV |
电流范围 |
0-120A |
0-1200A |
0-150A |
0-1500A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
0-120A |
0-1200A |
精度 |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
0.05%+0.1%FS |
||||||
分辨率 |
2.5mA |
25mA |
3mA |
30mA |
2.5mA |
25mA |
2.5mA |
25mA |
2.5mA |
25mA |
2.5mA |
25mA |
功率范围 |
0-1200W |
0-12000W |
0-1500W |
0-15000W |
0-1800W |
0-18000W |
0-2400W |
0-24000W |
0-3000W |
0-30000W |
0-4000W |
0-40000W |
精度 |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
0.2%+0.2%FS |
||||||
分辨率 |
0.1W |
0.1W |
0.1W |
0.1W |
0.1W |
0.1W |
||||||
常规参数 |
||||||||||||
短路电流 |
1200A |
1500A |
1200A |
1200A |
1200A |
1200A |
||||||
尺寸 (W*H*D) mm |
550 X 810 X 720 |
550 X 990 X 720 |
550 X1165 X 720 |
550 X 1520 X 720 |
880 X1520 X 720 |
880X1680 X 720 |
||||||
重量 (Kg) |
153 |
202 |
242 |
316 |
400 |
496 |
||||||
